2. Remove the main bearing caps and carefully lift the crankshaft out of the engine block.

a - Crankshaft

b - Main bearing cap

c - Rear main bearing cap

d - Main bearing cap screw

a - Crankshaft

59495

59493

Engine Disassembly
