6. Tighten the intake manifold bolts to the specified torque in the sequence and steps indicated.
Torque sequence
Tube Ref No. Description Where Used Part No.
66
Loctite 242 Threadlocker Intake manifold bolt threads 92-809821
Description Nm lb‑in. lb‑ft
Intake manifold bolts
First torque
12 106.2 –
Second torque
24 – 17.7
7.
Install the alternator. Refer to Section 4C ‑ Alternator Installation.
8.
Install the fuel injector rail with injectors. Refer to Section 5A ‑ Fuel Rail Installation.
9. Connect the injector wire harness.
10. Install the fuel line.
11. Connect all ignition and electrical leads.
12. Install other ignition components and connect the wires.
13. Connect the crankcase ventilation hoses.
14. Connect any items that were disconnected.
Engine Inspection and Assembly
90-8M0099748 eng DECEMBER 2015 © 2016 Mercury Marine Page 3B-61
