4. Install the exhaust tube and the intermediate exhaust pipe onto the exhaust Y‑pipe and secure with hose clamps. Tighten
the hose clamps to the specified torque.
a - Exhaust tube
b - Exhaust Y‑pipe
c - Hose clamps
Description Nm lb‑in. lb‑ft
Tridon
®
hose clamp (exhaust tube)
4‑4.7 35.4‑41.6 –
c
a
c
b
18530
Exhaust Pipe and Through-the-Propeller Exhaust
Page 7C-10 © 2016 Mercury Marine 90-8M0099748 eng DECEMBER 2015
