Power-Assisted Steering Components Exploded View
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Cap and dipstick
2 1 Power steering reservoir
3 1 Clamp
4 2 Clamp
5 1 Oil pump to reservoir hose
6 1 Pulley
7 3 Screw
8 1 Pump assembly
9 1 Pump to cylinder hose 31 – 23
10 1 O‑ring (0.301 x 0.064)
11 1 Clip
12 1 Reservoir to cooler hose
13 1 Power steering cylinder
14 2 Stainless steel screw
15 3 Screw
16 1 Bracket
17 1 Strap
18 1 Clevis pin
19 1 Clevis pin
20 2 Cotter pin
21 1 O‑ring
22 1 O‑ring
23 1 Fitting
24 1 Fitting
25 1 Cylinder to cooler hose
26 1 Clamp
27 1 Power steering cooler
28 1 Sensor
29 2 Elbow (45°)
30 2 Cable tie
31 1 Fitting to the transom
32 1 Clamp
Power-Assisted Steering Pump and Related Components
90-8M0099748 eng DECEMBER 2015 © 2016 Mercury Marine Page 8A-5
