6.3 Storing test results
After the completion of a test the results and parameters are ready for storing ( icon
is displayed in the information field). By pressing the MEM key, the user can store the
results.
Figure 6.2: Save test menu
Memory available for storing results.
Keys in save test menu - data structure field:
TAB
Selects the location element (Object / Block / Fuse /
Connection).
UP / DOWN
Selects number of selected location element (1 to 199).
MEM
Saves test results to the selected location and returns to the
measuring menu.
Function selector /
TEST
Exits back to main function menu.
Notes:
 The instrument offers to store the result to the last selected location by default.
 If the measurement is to be stored to the same location as the previous one just
press the MEM key twice
