METREL EurotestCOMBO MI 3125 - AUS; NZ Modification - Fuse Types According to AS;NZS 3017

MI 3125 / BT EurotestCOMBO Appendix C
81
C.2.3.2 New chapter
For selection of proper supply system, the chapter 4.2.9 is added.
4.2.9. Supply earthing system
In this menu the tested supply system can be
selected.
Figure 4.9: Selection of supply system
Keys:
UP / DOWN
Selects distribution supply system.
TEST
Confirms selected system and exits to settings menu.
Function selector
Exits back to main function menu.
C.2.3.3 New appendix D for IT supply system
C.2.4 AUS / NZ modification – Fuse types according to AS/NZS 3017
Modifications of the chapter 4.2
I
SC
factor is replaced with Z factor.
Figure 4.1: Options in
Settings menu
Modifications of the chapter 4.2.5
C.2.4.1 Z Factor
In this menu the Z factor can be set.
Figure 4.6: Selection of Z
factor
