METREL EurotestXE User Manual

MI 3102(H) BT EurotestXE Autosequences
75
Keys in auto-sequence and editing parameters menu
Key
Auto-sequence menu
Editing parameters menu
TAB
Enters viewing/editing
test parameters.
Selects the test parameter to be set or
modified.
UP / DOWN
Sets or modifies test parameters.
TEST
Runs selected auto-
sequence.
Runs selected auto-sequence.
HELP / CAL
Click
Switch between
screens.
Measuring reference line impedance (when
ZREF is selected).
HELP / CAL
Keep pressed for 1 s
Enters help screens.
Enters help screens.
MEM
Stores auto-test results.
ESC
Exits back to previous
menu.
Exits back to previous menu with saving
changes.
The following tests / measurements can be performed for selected autosequence. Parameters
in each auto-sequence are user-defined as follows.
Auto-sequence
Test /
measurement
Available editable parameters
AUTO TT
VOLTAGE
Z LINE
U*
Zs rcd
Uc
FUSE
fuse type, rated current, maximal braking
time, minimal short-circuit current
ZREF
reference line impedance
∆U
voltage drop limit value
RCD
nominal current, RCD type, maximal
contact voltage
AUTO TN (RCD)
VOLTAGE
Z LINE
U*
Zs rcd
Rpe(rcd)
FUSE
fuse type, rated current, maximal braking
time, minimal short-circuit current
ZREF
reference line impedance
∆U
voltage drop limit value
RPE
maximal PE line resistance
AUTO TN
VOLTAGE
Z LINE
U*
Z LOOP
Rpe
FUSE
fuse type, rated current, maximal braking
time, minimal short-circuit current
ZREF
reference line impedance
∆U
voltage drop limit value
RPE
maximal PE line resistance
AUTO IT
VOLTAGE
Z LINE
U*
ISFL
IMD
FUSE
fuse type, rated current, maximal braking
time, minimal short-circuit current
ZREF
reference line impedance
∆U
voltage drop limit value
ISFL
maximal leakage current
IMD
test type, minimal insulation or maximal
leakage current
* applicable only if Z
REF
is set
