3.7 Connecting the 805 Dosimat
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
14
￭￭￭￭￭￭￭￭
876 Dosimat plus
3.7 Connecting the 805 Dosimat
For tandem operation (XDOS mode), an 805 Dosimat can be connected to
the MSB 1 socket on the rear of the 876 Dosimat plus.
Figure 12 Connecting the 805 Dosimat
CAUTION
Make sure that the flat side of the plug matches the marking on the
socket.
If the MSB 1 connector is already occupied by a stirrer (e.g. 801 Stirrer),
then the 805 Dosimat can be connected to the MSB socket of the stirrer.
Figure 13
MSB connector on the 801 Stirrer
CAUTION
Make sure that the flat side of the plug matches the marking on the
socket.
The 876 Dosimat plus must be switched off and then on again after con-
nection.
