4 Operation
876 Dosimat plus
￭￭￭￭￭￭￭￭
25
4.4 Stirrer operation
You can control a connected stirrer directly in the main dialog.
Proceed as follows:
1
Set the stirring rate
￭ Use the arrow key [↓] to select the Stirrer entry.
￭ In the function bar, select the Stir- or Stir+ function.
The stirring rate will be increased or decreased by one step each
time the [OK] key is pressed.
The algebraic sign changes the direction in which the stirring is
done. When the stirrer is viewed from above, this means:
– "+": counterclockwise rotation
– "–": clockwise rotation
2
Switch on the stirrer
￭ In the function bar, select the on function and press [OK].
The stirrer is started and stirs at the rate which has been set. Off is
now displayed in the function bar.
3
Switch off the stirrer
￭ In the function bar, select the off function and confirm with [OK].
The stirrer is stopped.
