5.4 Configuring external devices
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
36
￭￭￭￭￭￭￭￭
876 Dosimat plus
Directory structure on the USB flash drive
A directory with the instrument number will be created on the USB flash
drive. The structure within this directory appears as follows:
Figure 16 Directory structure on the USB flash drive
Backup All of the files of the backup are stored in this
directory. The directory is created as soon as a
backup is created for the first time.
Files Exported methods are stored in this directory.
The directory is created as soon as a backup is
exported for the first time.
Only methods located in this directory can be
imported.
5.4 Configuring external devices
Menu ▶ System ▶ External devices
PC/LIMS report
Specification of the storage location for the PC/LIMS report. The PC/LIMS
report is a machine-readable report with all of the important data for a
determination. It can be saved as follows:
￭ as a TXT file on a USB flash drive.
￭ to a LIMS via an RS-232 interface. The 6.2148.030 RS-232/USB Box is
required for this purpose.
Selection COM2 | USB Stick
Default value USB Stick
COM2
The report is sent via the serial COM2 interface. The interface parame-
ters set in the dialog COM2 settings are used (see "Editing the COM2
settings", page 38).
USB Stick
The report will be saved as a TXT file on the USB flash drive in the
folder pc_lims_report.
Printer
If a printer is connected, then the printer type needs to be defined here in
order for the reports to be printed out correctly.
