Quadra-Chek

QC200

3-15

DMS/DD

Toggles the display of angles between degrees, minutes and seconds and decimal

degrees.

MCS

Highlight MCS to clear datums and re-establish machine coordinates.

NOTENOTE

NOTE

Previous datums cannot be recovered once machine coordinatesPrevious datums cannot be recovered once machine coordinates

Previous datums cannot be recovered once machine coordinates

are re-established.are re-established.

are re-established.

MinMax

Highlight MinMax to collect minimum and maximum point values until the

finish key is pressed. Use MinMax for touch-probe measurements of runout.

Preset

Highlight preset to preset an axis or axes to a desired feature or location. Use the

preset function to measure features that are datumed on another part. Typically

this is required for component parts of larger assemblies. Another use for the

preset function is to find the offset between the nominal and actual location of a

preset feature.

Preset!

Sets the axis or axes to the last entered preset location.

Run! (run last program)

Highlight run! to run the last program again.

NOTENOTE

NOTE

All send data menu items send data to the RS-232 port. TheseAll send data menu items send data to the RS-232 port. These

All send data menu items send data to the RS-232 port. These

commands do not send data through the parallel port.commands do not send data through the parallel port.

commands do not send data through the parallel port.

Send 2

Select send 2 to send the current X and Y axes data to a printer or computer.

Send D

Select send D to send the current diameter data to a printer or computer.

Send L

Select send L to send the current length data to a printer or computer.

Send r

Select send r to send the current radius data to a printer or computer.
