2.3.4 Connection between PC Recorder and I/O unit
The I/O unit and PC Recorder are connected following the procedure below:
(1) Connect the I/O unit to the PC with a USB cable. When power is supplied from the PC to the I/O unit,
the PWR indicator LED on the I/O unit lights in green.
(2) Check the connection to the I/O unit. When the I/O unit and PC Recorder are connected properly, the
RUN indicator LED on the I/O unit lights in green. It does not light up when operating in the Demo mode.
->3.1 I/O connection setting
