MG PC Series - Folder Structure

Recording data 4.4 Folder structure
EM-7361 P57
MG CO., LTD.
www.mgco.jp
Folder structure
Each file is saved based on the Windows “Documents” folder “C:¥Users¥[USERNAME]M-System¥PC
Recorder.”
([USERNAME] depends on the account.)
The folder structure under PC Recorder is shown in the figure below. Year/Month/Day folders are
automatically created as more files are saved.
 PC Recorder
│ Log.txt ························································· System log file
├ RPT ·························································· Report folder
│ └ 2023 ······················································· Folder for 2023
│ │ RPT2023.CSV
│ ├ 10 ··················································· Folder for October
│ │ RPT202310.CSV
│ │ RPT20231031.CSV
│ └ 11 ··················································· Folder for November
│ RPT202311.CSV
│ RPT20231101.CSV
└ TREND ······················································ Trend Folder
│ └ 2023 ··················································· Folder for 2023
│ ├ 10 ················································ Folder for October
││ 20231029103020100.TRD
│├ 30 ················································ Folder for 30th
││ 20231030150050000.TRD
│└ 31 ················································ Folder for 31st
│ 20231031084510500.TRD
└ 11 ··················································· Folder for November
│ 20231101003000000.TRD
└ 01 ·············································· Folder for 1st
20231101010000000.TRD
● When the trend data recording speed is set to 10 s, 1 m, 2 m, 5 m, 10 m, 30 m, or 1 h, trend
files are saved in the month folders.
CAUTION
