Report file
Report files are saved in CSV format.
File name
Daily report files are created with a name consisting of the year, month, and day (yyyymmdd) of the first sample,
monthly report files with a name consisting of the year and month (yyyymm) of the first sample, and yearly
report files with a name consisting of the year (yyyy) of the first sample. Also. for the folder structure, refer to
4.4 Folder structure.
When the settings are changed, it is recorded with “_X” added to the end of the file name. The previously
recorded reports are confirmed at the time of change.
If the file in which the report data is saved is opened in Excel or another application and cannot be saved, “_S”
is added to the end of the file name and the file is temporarily saved.
Report
How to name a file
Example:
Daily report
Year, month, and day followed by “RPT”
RPT20231025.CSV, RPT20231025_X.CSV,
RPT20231025_S.CSV
Monthly report
Year and month followed by “RPT”
RPT202310.CSV, RPT202310_X.CSV,
RPT202310_S.CSV
Yearly report
Year followed by “RPT”
RPT2023.CSV, RPT2023_X.CSV, RPT2023_S.CSV
The format of each CSV file is as follows (when 16 channels are assigned):
Daily report
Row 1
Row 2
Row 3
・・・
Row 17
Line 1
Title of daily
report
Line 2
(Blank)
CH1 name
CH2 name
・・・
CH16 name
Line 3
A.D.
year/month/day
CH1 comment
CH2 comment
・・・
CH16 comment
Line 4
(Blank)
CH1 engineering unit
CH2 engineering unit
・・・
CH16 engineering unit
Line 5
1 o’clock
CH1 data
CH2 data
・・・
CH16 data
Line 6
2 o’clock
CH1 data
CH2 data
・・・
CH16 data
・・・
・・・
・・・
・・・
・・・
・・・
Line 28
24 o’clock
CH1 data
CH2 data
・・・
CH16 data
Line 29
Total
CH1 total value
CH2 total value
・・・
CH16 total value
Line 30
Average
CH1 average value
CH2 average value
・・・
CH16 average value
Line 31
Maximum
CH1 maximum value
CH2 maximum value
・・・
CH16 maximum value
Line 32
Minimum
CH1 minimum value
CH2 minimum value
・・・
CH16 minimum value
