Appendix 8.1 Troubleshooting
EM-7361 P79
MG CO., LTD.
www.mgco.jp
8. Appendix
Troubleshooting
Also refer to the “Frequently Asked Questions (FAQ)” on our Website.
https://www.mgco.jp/
8.1.1 I/O unit : lamp indication
Phenomenon
Check item
Measure
The PWR indicator lamp
does not light up.
Is the I/O unit turned on?
Check the connection to the PC.
The RUN indicator lamp
does not light up.
Is the I/O unit set in the
connection settings?
Right-click the “PC Recorder” icon in the task
tray to open the menu. Click [Settings] to show
the “Settings” display and then click [Connect].
Show the “Connection” display and check the
[I/O] settings. ->3.1 I/O connection setting
8.1.2 PC Recorder
Phenomenon
Check items
Measure
Unable to connect to the I/O
unit.
Is the I/O unit set in the
connection settings?
Right-click the “PC Recorder” icon in the task
tray to open the menu. Click [Settings] to show
the “Settings” display and then click [Connect].
Show the “Connection” display and check the
[I/O] settings. ->3.1 I/O connection setting
Unable to display the screen
on the Web browser.
Is the port number used by PC
Recorder (default: 38080) open?
Check the firewall settings on the PC.
Trend data is not displayed.
Are the trend settings correct?
Right-click the “PC Recorder” icon in the task
tray to open the menu. Click [Settings] to show
the “Settings” display and then click [Trend].
Show the “Trend” display and check the
settings. ->3.4 Recording trend
Reports are not recorded.
Are the report settings correct?
Right-click the “PC Recorder” icon in the task
tray to open the menu. Click [Settings] to show
the “Settings” display and then click [Report].
Show the “Report” display and check the
settings. ->3.5 Recording report
Trend and report data are
not recorded.
Is PC Recorder started?
Even if the PC and the I/O unit are connected,
the data are not recorded if PC Recorder is not
started up.
