View 5.2 Trend display
EM-7361 P61
MG CO., LTD.
www.mgco.jp
For items that are displayed differently depending on the type of input/output, refer to the table below.
Item
Type
Description
Digital display
AI
Displays the % value or the actual quantity value.
DI
DO
Displays the display comment corresponding to ON/OFF.
OI
Displays the numerical value of the actual quantity.
Status
AI
OI
When a zone is used, the current display color is shown.
When a zone is not used, the pen color is shown.
This is displayed in a simple bar graph manner. The display color
corresponding to the whole status is shown.
DI
DO
Display color corresponding to ON/OFF as a bar.
Engineering unit
AI
OI
Displays the specified unit.
DI
DO
Blank.
