6
Range
10mV~2Vrms
Resolution
1mV
Voltage Signal Level
Accuracy
4-Terminal test fixture
± [(10 + 0.05 × f )% + 1 mV]
*f : frequency [MHz]
Cable length > 0m
± [(15 + 0.1 × f )% + 1 mV]
Range
200µA~ 20mArms
Resolution
10µA
Accuracy
4-Terminal test fixture
Current Signal Level
at
15MHz
+[10% + 50 μA], –[(10 + 0.2 × f 2 )% + 50 μA]
at
15MHz
± [(10 + 0.3 × f )% + 50 μA]
Cable length > 0m
at
5MHz
+[10% + 50 μA], –[(15 + 1.5 × f 2 )% + 50 μA]
*f : frequency [MHz]
at
15MHz
± [(20 + 0.3 × f )% + 50 μA]
Measurement Time
<3ms(The fastest)
Output Resistance
25Ω/100Ω, switchable
Parameter
|Z|
|Y|
θ
X
R
G
B
L
D
Q
DCR
C
Vdc-Idc
ESR
ε
µ
Calibration
Open Circuit/ Short Circuit/Load Calibration
Measurement Circuit
Series/Parallel
Multi-steps Mode
50 setup groups (with each group containing 15 measuring steps)
PCLINK
CPK
Equivalent Circuit
Analysis
Option
Flash Memory
100 LCR-measure Mode setup documents& 50 Multi-steps Mode setup
documents
USB Memory
LCR-measure Mode setup document
Multi-steps Mode setup document
BMP
graphics
Test result data
Sweep Mode BMP graphics& result data
Interface
I/O Interface
Handler
USB
RS232
Parallel interface
Serial interface
GPIB
Display
7.0”TFT, 800*480color screen
Environment
10°C~40°C,≤80%RH
Power Supply
Voltage
90~264Vac
Frequency
47~63Hz
Power Consumption
Low power consumption: Maximum 30W (Nominal value)
Dimension(W*H*D)
336x147x340mm
Weight
3kg
