4.10 Parameters
Press <Menu> key to select <Meter> mode and then move the cursor to the left
side for setting the parameters to be measured.
Equivalent Series Inductance
Equivalent Parallel Inductance
Equivalent Series Capacitance
Equivalent Parallel Capacitance
Quality Factor, (Q = 1/D)
Dissipation Factor
, Loss coefficient (tanδ)
Equivalent Series Resistance (ESR)
Equivalent Parallel Resistance
Absolute value of impedance
Phase angle of impedance(degree)
Phase angle of impedance(radian)
Absolute value of admittance
Relative Permittivity, Dielectric constant
When selecting parameter ε or μ, it is required to set ε
r
and μ
r
(see 4.10 SET ε
r
and 4.11 SET μ
r
)
