81
<Command>
:SWEep:STOP <stopNR3/disc>
:SWEep:STOP?
FunctionIt sets or queries the STOP.
Description
Set parameterThe stop value of frequency is {10.0~30000000.0|MAXimum|MINimum}.
The stop value of
voltage AC RO 10
is {0.01~2|MAXimum|MINimum}.
The stop value of
voltage AC RO
25Ω is {0.01~1|MAXimum|MINimum}.
The stop value of current
AC RO 10
is {
0.0002~0.02
|MAXimum|MINimum}.
The stop value of current
AC RO
25Ω is {
0.0002~0.04|MAXimum|MINimum}.
Set syntax
:SWEep:STARt 0.5
:SWEep:STARt 500M
:SWEep:STARt 5E-3
:SWEep:STARt MAXimum
:SWEep:STARt MINimum
Querysyntax
:SWEep:STARt?
Return
data+5.000000E-01(Format is in <NR3>)
<Command>
:SWEep:FREQuency<frequencyNR3/disc>
:SWEep:FREQuency?
FunctionIt sets or queries the FREQ, when the TYPE setup is VAC or IAC.
Description
Set parameter
The value of frequency is {10.0~30000000.0|MAXimum|MINimum}.
Set syntax
:SWEep:FREQuency 1000
:SWEep:FREQuency 1K
:SWEep:FREQuency 1KHZ
:SWEep:FREQuency 1E3
:SWEep:FREQuency MAXimum
:SWEep:FREQuency MINimum
Query syntax
:SWEep:FREQuency?
Return
data 1.000000E+03(Format is in <NR3>)
When the TYPE setup is FREQuency mode, the data returns 9.9E37.
<Command>
:SWEep:VOLTage <voltage NR3/disc>
:SWEep:VOLTage?
FunctionIt sets or queries the LEVEL to voltage mode, when the TYPE setup is FREQ.
Description
Set parameterThe value of
voltage AC RO 100Ω
is {0.01~2|MAXimum|MINimum}.
The value of
voltage AC RO
25Ω is {0.01~1|MAXimum|MINimum}.
Set syntax
:SWEep:VOLTage 1
:SWEep:VOLTage 1M
:SWEep:VOLTage 1MV
:SWEep:VOLTage 1E-3
:SWEep:VOLTage MAXimum
:SWEep:VOLTage MINimum
Query syntax
:SWEep:VOLTage?
Return data 1.000000E+03(Format is in <NR3>)
When the LEVEL setup is not voltage mode, the data returns 9.9E37.
