Mikro DPM680 - Maximum Phase Voltage; Minimum Phase Voltage

22
3.3.3
MaxiMuM pHasE VolTaGE
The Maximum Phase Voltage page shows the
recorded maximum true RMS phase voltage with
the corresponding time and date since the last
reset as shown in Fig 22:
The time and date records are displayed in the
hour:minute:second day-month-year format.
In clearing the recorded values, the user will be
prompted with a Clear Logged Data? conrmation.
When these recorded values are cleared, the
corresponding time and date records are also
cleared to the default 00:00:00 00-00-2000.
3.3.4
MiniMuM pHasE VolTaGE
The Minimum Phase Voltage page shows the
recorded minimum true RMS phase voltage with
the corresponding time and date since the last
reset as shown in Fig 23:
Fig 22 : Maximum Phase Voltage page
Fig 23 : Minimum Phase Voltage page
TouCH BuTTon funCTions:
• to reset the recorded maximum voltage
values to zero, touch the RESET (F3) button.
• otherwise, touch the BACK (F1) button to
return to the VOLTAGE sub-menu.
TouCH BuTTon funCTions:
• to conrm clearing the recorded values, touch
the YES (F4) button.
• otherwise, touch the NO (F2) button.
Meter Operations 3.3.3 3.3.4
