Meter Operations 3.8.1 3.8.2
The user will be prompted to conrm the saving
of settings.
3.8.2
CoMMuniCaTion sETTinGs
(onlY for DpM680)
The Communication Settings page displays
and allows the setting of the communication
parameters as shown in Fig 73.
Fig 73 : Communication Settings page
TouCH BuTTon funCTions:
• to abort saving the settings, touch the NO
(F3) button to return to the SETTING sub-
menu.
• otherwise, touch the YES (F2) button to save
the settings and the user will be prompted for
password authentication as in section 3.2.
TouCH BuTTon funCTions:
• to select the parameter sub-page of interest,
touch either the UP (F2) or DOWN (F3)
button until the parameter item is highlighted
(within a dashed rectangular box and a RED
dot to its left). To conrm this selection, touch
the ENTER (F4) button.
• to return to the SETTING sub-menu, touch
the BACK (F1) button.
