Mikro DPM680 - Minimum Apparent Power

53
TouCH BuTTon funCTions:
• to conrm clearing the recorded values,
touch the YES (F4) button.
• otherwise, touch the NO (F2) button.
TouCH BuTTon funCTions:
• to reset the recorded minimum apparent
power values to zero, touch the RESET
(F3) button.
• otherwise, touch the BACK (F1) button to
return to the POWER sub-menu.
In clearing the recorded values, the user will
be prompted with a Clear Logged Data?
conrmation.
The time and date records are displayed in the
hour:minute:second day-month-year format.
When these recorded values are cleared, the
corresponding time and date records are also
cleared to the default 00:00:00 00-00-2000.
3.6.12
MiniMuM apparEnT powEr
The Minimum Apparent Power page shows
the recorded minimum apparent power for each
phase as well as the minimum total apparent
power with the corresponding time and date
since the last reset as shown in Fig 65:
Fig 65 : Minimum Apparent Power page
Meter Operations 3.6.12
