Mikro DPM680 - Maximum Current

30
Meter Operations 3.4.2
3.4.2
MaxiMuM CurrEnT
The Maximum Current page shows the
recorded maximum true RMS current of each
phase and where applicable, neutral with the
corresponding time and date since the last reset
as shown in Fig 34:
Fig 34 : Maximum Current page
In clearing the recorded values, the user
will be prompted with a Clear Logged Data?
conrmation.
When these recorded values are cleared, the
corresponding time and date records are also
cleared to the default 00:00:00 00-00-2000.
TouCH BuTTon funCTions:
• to conrm clearing the recorded values, touch
the YES (F4) button.
• otherwise, touch the NO (F2) button.
The time and date records are displayed in the
hour:minute:second day-month-year format.
TouCH BuTTon funCTions:
• to reset the recorded maximum current values
to zero, touch the RESET (F3) button.
• otherwise, touch the BACK (F1) button to
return to the CURRENT sub-menu.
