66
Meter Operations 3.8.3.3 3.8.3.4
In the input mode, the UP (F2) and DOWN (F3)
buttons will become active and the background
colour of the active eld will be changed to white.
TouCH BuTTon funCTions:
• to increase the number, touch the UP (F2)
button.
• to decrease the number, touch the DOWN
(F3) button.
• to select the next eld to change, touch the
NEXT (F1) button and repeat the above 2
steps.
• when all the elds are lled, touch the
ENTER (F4) button and the SAVE (F1)
button will appear.
• touch the SAVE (F1) button and if the
New Password does not match with the
Re-entered password, an error message
will appear and the above process has to
be repeated unless aborted by touching the
BACK (F1) button. If the password is correct,
it will be saved and the display will return to
the System Settings page.
The password for this purpose is the factory
setting password. Please see section 3.2 for
more details.
3.8.3.4
faCTorY sETTinGs
The Factory Settings sub-page displays a
warning message that all settings (and device
password) will be reset to the factory default
values except the energy register values. (The
energy registers can be cleared through the
Reset Energy Counter page as in section 3.7.5)
TouCH BuTTon funCTions:
• to abort resetting the meter to default values,
touch the NO (F3) button to return to the
System Settings page.
• otherwise, touch the YES (F2) button and
the user will be prompted for password
authentication as in section 3.2.
