26
3.3.9
VolTaGE HarMoniCs
TaBlE
The Voltage Harmonics Table page shows
the harmonic voltages as a percentage of the
fundamental voltage for each phase up to the
32
nd
order as shown in Fig 29 for phase L1:
Fig 29 : Phase L1 Voltage Harmonics page
In the Voltage THD parameter page, the voltage
THD for each phase is displayed as shown in
Fig 28.
Fig 28 : Voltage THD parameter page
TouCH BuTTon funCTions:
• to return to the Voltage Harmonics page,
touch the BACK (F4) button
TouCH BuTTon funCTions:
• to alternate between the odd and even
harmonics spectrum display, touch the EVEN
(F2) or ODD (F2) button.
• to display the spectrum of the next phase,
touch the NEXT (F3) button.
• to jump to the THD parameter page as shown
in Fig 28 below, touch the THD (F1) button.
• otherwise, touch the BACK (F4) button to
return to the VOLTAGE sub-menu.
Meter Operations 3.3.8 3.3.9
