Mikro DPM680 - Maximum Line Voltage

23
The time and date records are displayed in the
hour:minute:second day-month-year format.
The time and date records are displayed in the
hour:minute:second day-month-year format.
In clearing the recorded values, the user
will be prompted with a Clear Logged Data?
conrmation.
When these recorded values are cleared, the
corresponding time and date records are also
cleared to the default 00:00:00 00-00-2000.
3.3.5
MaxiMuM linE VolTaGE
The Maximum Line Voltage page shows the
recorded maximum true RMS line voltage with
the corresponding time and date since the last
reset as shown in Fig 24:
Fig 24 : Maximum Line Voltage page
TouCH BuTTon funCTions:
• to reset the recorded minimum voltage values
to zero, touch the RESET (F3) button.
• otherwise, touch the BACK (F1) button to
return to the VOLTAGE sub-menu.
TouCH BuTTon funCTions:
• to reset the recorded maximum voltage
values to zero, touch the RESET (F3) button.
• otherwise, touch the BACK (F1) button to
return to the VOLTAGE sub-menu.
TouCH BuTTon funCTions:
• to conrm clearing the recorded values, touch
the YES (F4) button.
• otherwise, touch the NO (F2) button.
In clearing the recorded values, the user
will be prompted with a Clear Logged Data?
conrmation.
TouCH BuTTon funCTions:
• to conrm clearing the recorded values, touch
the YES (F4) button.
• otherwise, touch the NO (F2) button.
Meter Operations 3.3.4 3.3.5
