Mikro DPM680 - Maximum Active Power

48
Meter Operations 3.6.6 3.6.7
TouCH BuTTon funCTions:
• to reset the recorded maximum power
demand values to zero, touch the RESET
(F3) button.
• otherwise, touch the BACK (F1) button to
return to the POWER sub-menu.
TouCH BuTTon funCTions:
• to reset the recorded maximum active power
values to zero, touch the RESET (F3) button.
• otherwise, touch the BACK (F1) button to
return to the POWER sub-menu.
TouCH BuTTon funCTions:
• to conrm clearing the recorded values,
touch the YES (F4) button.
• otherwise, touch the NO (F2) button.
In clearing the recorded values, the user will
be prompted with a Clear Logged Data?
conrmation.
3.6.7
MaxiMuM aCTiVE powEr
The Maximum Active Power page shows the
recorded maximum active power for each phase
as well as the maximum total active power with
the corresponding time and date since the last
reset as shown in Fig 60:
Fig 60 : Maximum Active Power page
The time and date records are displayed in the
hour:minute:second day-month-year format.
The time and date records are displayed in the
hour:minute:second day-month-year format.
When these recorded values are cleared, the
corresponding time and date records are also
cleared to the default 00:00:00 00-00-2000.
