Milesight UG63 - 3.3.2.7 Certifications

52
Local Tunnel IP
Set local tunnel address.
Remote Tunnel IP
Enter remote tunnel address.
Global Traffic
Forwarding
All the data traffic will be sent out via OpenVPN tunnel when
this function is enabled.
Enable TLS
Authentication
Check to enable TLS authentication.
Username
Enter username provided by OpenVPN server.
Password
Enter password provided by OpenVPN server.
Compression
Select LZO to compress data.
Link Detection Interval
(s)
Set link detection interval time to ensure tunnel connection.
Range: 10-1800.
Link Detection Timeout
(s)
Set link detection timeout. OpenVPN will be reestablished
after timeout. Range: 60-3600.
Cipher
Select from "NONE", "BF-CBC", "DE-CBC", "DES-EDE3-CBC",
"AES-128-CBC", "AES-192-CBC" and "AES-256-CBC".
MTU
Enter the maximum transmission unit. Range: 128-1500.
Max Frame Size
Set the maximum frame size. Range: 128-1500.
Verbose Level
Select from "ERROR", "WARING", "NOTICE" and "DEBUG".
Expert Options
User can enter some other PPP initialization strings in this
field and separate the strings with blank space.
Table 3-3-2-9 OpenVPN Client Parameters
3.3.2.7 Certifications
User can import/export certificate and key files for OpenVPN and IPsec on this page.
Figure 3-3-2-13
OpenVPN Client
Item
Description
CA
Import/Export CA certificate file.
Public Key
Import/Export public key file.
