37
False: ADR is disabled or Network does not respond in
ADR_ACK_DELAY.
Ack
True: This frame is ACK.
False: This frame is not ACK.
Fcnt
Show the frame-counter of this packet.The network server tracks the
uplink frame counter and generates the
downlink counter for each end-device.
FPort
FPort is a multiplexing port field. If the frame payload field is not
empty, the port field must be present. If present, a FPort
16 value of 0 indicates that the FRMPayload contains MAC commands
only.When this is the case, the FOptsLen field must be zero. FOptsLen
is the length of the FOpts field in bytes.
Modulation
LoRa means the physical layer uses the LoRa modulation.
Bandwidth
Show the bandwidth of this channel.
SpreadFactor
Show the spreadFactor of this channel.
Bitrate
Show the bitrate of this channel.
CodeRate
Show the coderate of this channel.
SNR
Show the SNR of this channel.
RSSI
Show the RSSI of this channel.
Power
Show the transmit power of the device.
Payload (b64)
Show the application payload of this packet.
Payload (hex)
Show the application payload of this packet.
MIC
Show the MIC of this packet. MIC is a cryptographic message integrity
code, computed over the fields MHDR, FHDR, FPort and the encrypted
FRMPayload.
Table 3-2-2-14 Packets Details Parameters
Related Topic
Send Data to Device
3.3 Network
3.3.1 Interface
3.3.1.1 Port
The Ethernet port can be connected with Ethernet cable to get Internet access. It supports
3 connection types.
- Static IP: configure IP address, netmask and gateway for Ethernet WAN interface.
- DHCP Client: configure Ethernet WAN interface as DHCP Client to obtain IP address
automatically.
- PPPoE: configure Ethernet WAN interface as PPPoE Client.
