UG65 User Guide
www.milesight-iot.com
56
Figure 3-3-2-4
Port Mapping
Item
Description
Source IP
Specify the host or network which can access local IP address.
0.0.0.0/0 means all.
Source Port
Enter the TCP or UDP port from which incoming packets are
forwarded. Range: 1-65535.
Destination IP
Enter the IP address that packets are forwarded to after being
received on the incoming interface.
Destination Port
Enter the TCP or UDP port that packets are forwarded to after
being received on the incoming port(s). Range: 1-65535.
Protocol
Select from "TCP" and "UDP" as your application required.
Description
The description of this rule.
Table 3-3-2-4 Port Mapping Parameters
Related Configuration Example
NAT Application Example
3.3.2.5 MAC Binding
MAC Binding is used for specifying hosts by matching MAC addresses and IP addresses
that are in the list of allowed outer network access.
Figure 3-3-2-5
MAC Binding List
Item
Description
MAC Address
Set the binding MAC address.
