Milesight UG65 - Page 64

UG65 User Guide
www.milesight-iot.com
64
Figure 3-3-6-3
IPsec
Item
Description
Enable
Enable IPsec tunnel. A maximum of 3 tunnels is allowed.
IPsec Gateway Address
Enter the IP address or domain name of remote IPsec
server.
IPsec Mode
Select from "Tunnel" and "Transport".
IPsec Protocol
Select from "ESP" and "AH".
Local Subnet
Enter the local subnet IP address that IPsec protects.
Local Subnet Netmask
Enter the local netmask that IPsec protects.
Local ID Type
Select from "Default", "ID", "FQDN", and "User FQDN".
Remote Subnet
Enter the remote subnet IP address that IPsec protects.
Remote Subnet Mask
Enter the remote netmask that IPsec protects.
Remote ID type
Select from "Default", "ID", "FQDN", and "User FQDN".
Table 3-3-6-2 IPsec Parameters
