120
Pellerin Milnor Corporation
Table 36 Parts List—Cylinder Assembly and Cylinder Door Installation (cont'd.)
Find the assembly for your machine and the letter shown in the "Item" column. The components for your machine will show this
letter or the word "all" in the "Used In" column. The numbers shown in the "Item" column are those shown in the illustrations.
Used In Item Part Number
Description/Nomenclature
Comments
all 20 03 06151 LATCHBODY-LARGE=CYLDOOR
all 21 X3 06150 PLUNGER=LARGE CYLDOOR(CAST)
all 22 03 06172 SHIM=DOOR LATCH-18GA
all 23 03 06173A SHIM=DOOR LATCH-11GA
all 24 02 18869 SPACER-LATCH PULL BND@PRNT
all 25 15K042 BUTSOKCAPSCR 1/4-20NCX1 SS18-8
all 26 15U181 LOCKWASHER MEDIUM 1/4 SS18-8
all 27 15G170 HEXNUT 1/4-20UNC2 SS18-8
all 28 15K042K BUTSOKCAPSCR 1/4-20UNCX1+1/4 S
all 29 02 15040 PLUNGER=CYLDOOR LATCH(CAST)
all 30 02 15041 BODY=CYLDOOR LATCH
all 31 02 15077 PLATE = SMALL DOORLATCH
all 32 02 15093 SPRING=DOOR LATCH 9.4#/INCH
all 33 15N173 FLATMACSCR 1/4-20NCX5/8SS18-8
all 34 15N158 HEXCAPSCR 1/4-20NCX1/2SS18-8
all 35 02 18990 PLATE=STOP + COVER 2/60+72WD
all 36 02 18864 PIN=LG CYL DOOR HINGE LARGE PIN
all 37 W2 18855 WLMT=HINGE LRG CYL DR MULT USED WITH ITEMS 3 & 5
all 37 W2 18866 WLMT=HINGE LRG CYL DR 2/60WE USED WITH ITEM 4
all 38 02 18865 PIN=SM CYL DOOR HINGE SMALL PIN
all 39 02 18858 HALFHINGE=60"WED CYLDOR SMAL
all 40 02 18989 PLATE-LATCH MTG2/WED+2/SGD
Cylinder Assembly and Cylinder Door Installation
5 Sheets
6044SR2, 7244SR2
Shell, Cylinder & Door
