124

Pellerin Milnor Corporation

Table 37. Parts List—Cylinder Doors 3 pocket

Find the assembly for your machine and the letter shown in the "Item" column. The components for your machine will show this

letter or the word "all" in the "Used In" column. The numbers shown in the "Item" column are those shown in the illustrations.

Used In Item Part Number

Description/Nomenclature

Comments

Reference Assemblies

A ACA36SG3A * CYL ASSY=7244SG3 WELD/SHAFT

Components

all 1 Y3 06162 MAINSHAFT 7244SG2+3

all 2 SA 36 003 CYLDOOR LOLT 72WE2+ MAX-REIF

all 3 SA 36 001 CYLDOOR LORT 72WE2+ MAX-REIF

all 4 SA 36 004 CYLDOOR UPLT 72WE2+ MAX-REIF

all 5

SA 28 116 * CYLDOR ASY,SMALL =60+72SG2

all 6 X2 15201 KEEPER=CYLDOOR LATCH(MONEL)

all 7 02 19183 COVER-DOORLATCH KEEP-OURMATL

all 8 03 06174 KEEPER=DOORLATCH REINFORCE

all 9 02 18962 STOP=CYLDOOR=42WEHU

all 10 02 18977A SHIM=CYL DRLATCH KEEPER-11GA

all 11 02 18977B SHIM=CYL DRLATCH KEEPER-14GA

all 12 02 18977C SHIM=CYL DRLATCH KEEPER-18GA

all 13 15K106E BUTSOKCAPSCR 3/8-16NCX1+1/2 SS

all 14 15U260 LOCKWASHER MEDIUM 3/8 SS18-8

all 15 15G206 HEXNUT 3/8-16 UNC2 SS 18-8

all 16 15A015 CARRSCR 3/8-16X1+1/4 18-8 SS

all 17 15K086 HXCAPSCR 3/8-16NCX3/4 SS18-8

all 18 X3 06166 KEEPER=CYL DOOR LATCH(MONEL)

all 19 03 06167 COVER-LARGE CYLDOOR KEEPER

all 20 15K084S HXCAPSCR 3/8-16NCX5/8 SS18-8

all 21 02 18818 CYL DOOR SM 60+72 WEDU

all 22 02 18854 PLATE=SM CYLDOOR REINFORCING

all 23 02 18991 PULL=DOORLATCH 2/WED+4/SGD

all 24 02 18865 PIN=SM CYL DOOR HINGE

all 25 W2 18858 WLMT=HINGE SM CYL DR 2/60WED

all 26 02 15040 PLUNGER=CYLDOOR LATCH(CAST)

all 27 02 15093 SPRING=DOOR LATCH 9.4#/INCH

all 28 02 18990 PLATE=STOP + COVER 2/60+72WD

all 29 02 18989 PLATE-LATCH MTG2/WED+2/SGD

all 30 02 15077 PLATE = SMALL DOORLATCH

all 31 02 15041 BODY=CYLDOOR LATCH

all 32 15N158 HEXCAPSCR 1/4-20NCX1/2SS18-8

all 33 15U181 LOCKWASHER MEDIUM 1/4 SS18-8

all 34 15G170 HEXNUT 1/4-20UNC2 SS18-8

all 35 15N173 FLATMACSCR 1/4-20NCX5/8SS18-8

all 36 03 06035 PIN=CYL DOOR HINGE 72WED

all 37 W3 06031 WLMT=HINGE HALF 72WED CYL DR

all 38 02 18869 SPACER-LATCH PULL BND@PRNT

all 39 03 06156 SPRING=LARGE CYLDOOR LATCH

Cylinder Doors 3 pocket

5 Sheets

7244WR3, 7244SR3

Shell, Cylinder & Door
