Table 37 Parts List—Cylinder Doors 3 pocket (cont'd.)
Find the assembly for your machine and the letter shown in the "Item" column. The components for your machine will show this
letter or the word "all" in the "Used In" column. The numbers shown in the "Item" column are those shown in the illustrations.
Used In Item Part Number
Description/Nomenclature
Comments
all 40 X3 06152 PLATE = LARGE DOORLATCH
all 41 03 06151 LATCHBODY-LARGE=CYLDOOR
all 42 X3 06150 PLUNGER=LARGE CYLDOOR(CAST)
all 43 15K042K BUTSOKCAPSCR 1/4-20UNCX1+1/4 S
all 44 15K042 BUTSOKCAPSCR 1/4-20NCX1 SS18-8
all 47 03 06173A SHIM=DOOR LATCH-11GA
all 48 03 06172 SHIM=DOOR LATCH-18GA
all 49 03 06317 STOP=CYLINDER DOOR LATCH
Cylinder Doors 3 pocket
5 Sheets
7244WR3, 7244SR3
Shell, Cylinder & Door
