Table 40. Parts List—Air Operated Autospot and Sensing Unit
Find the assembly for your machine and the letter shown in the "Item" column. The components for your machine will show this
letter or the word "all" in the "Used In" column. The numbers shown in the "Item" column are those shown in the illustrations.
Used In Item Part Number
Description/Nomenclature
Comments
Reference Assemblies
A G36 06700 AIROP AUTOSPOT ASSEMBLY-72SG2 REFERENCE
B E36 00300 * SENSE UNIT AUTOSPOT 72SG2 INSTALLATION
C E15 03000
$ BASIC 2-SWITCH AUTOSPOT ASY
SWITCH
D E15 03100
$CAM AS42WE2+SG2+DY2+60-72SG2
CAM
Components
A 1 54X020 SYNCHRONUS GEARBELT SPRKT
A 2 56Q0MHS .627" BUSH VPUL TYPE H,D,OR QT"SPECIAL"
A 3 12H050 HANDYBOX 4X2+1/8X2+1/8
A 4 12H095 HANDY BOX COVER 4+2+1/8
A 5
54C100 GEARBLT SYNC-COG DAYCO#420L050
A 6 02 10191 PULLEY-TIMING-DRIVER
A 7 15E007 KEY #7 WOODRUFF 3/4X1/8 SAE103
B 8 03 06415 LONG SUPPORT=72SG AIROP AS
B 9 03 06414 SHORT SUPPORT=72SG AIROP AS
B 10 03 06412 STIFFENER=AIROP AUTOSPOT-SG
B 11 03 06413 MTG PLATE=72SG AIROP ASS
B 12 03 01344 COVER=AIROP AUTOSPOT
B 13 03 01329 SHAFT=AIROPAUTOSPOT OUR MATL
B 14 02 10508 BEARING HOUSING- PLATED- ZINC
B 15 03 IF2X3 INSUL.AUTOSPOT/CENTRIFUGL.SW
B 16 02 02463 SPRING-CHART HOLDING
B 17 15P175 TRDCUT-F HXHD 1/4-20UNC2AX1/2
B 18 02 10507 BEARING HOUSING- CUP- PLATED
B 19 15N140 RDMACSCR 10-24UNC2AX3/4 ZINC G
B 20 15G125 HXMACHSCRNUT 10-24UNC2B ZINC G
all 21 15U150 LOCKWASHER MEDIUM #10 ZINCPL
all 22 15N125 RDMACSCR 10-24UNC2AX1/2 ZC GR2
all 23 15G219NTE HXTHINLOKNUT 3/8-24NF NYL STL/
B 24 15U238 LOKWAS INTOOTH 3/8" (US STD) 4
B 25 03 01328 HOUSING=AIROP AUTOSPOT
B 26 15K095 HXCPSCR 3/8-16UNC2AX1 GR5 ZINC
B 27 15G205 HXNUT 3/8-16UNC2B ZINC GR2
B 28 15U255 LOCKWASHER MEDIUM 3/8 ZINCPL
C 30 03 01343 SCREW-ADJ=AIROP AUTOSPOT
C 31 15G177 HXNUT 1/4-28UNF2B SAE ZINC GR2
C 32 03 01336 BKT-AIRCYL=AIRAUTOSPOT
C 33 27C205 AIRCYL 3/4"BORE X 1"STROKE
C 34 53A031B BODY-EL90MALE.25X1/8 #269C-42B
C 35 03 01357 PIVOT-SPRING=AIROP AUTOSPOT
C 36 17B006 EXTRETRING IND#1000-25-ST-ZD Z
C 37 03 01333 PIVOT=AIRCYL=AIROP AUTOSPOT
