Pellerin Milnor Corporation 137
Table 40 Parts List—Air Operated Autospot and Sensing Unit (cont'd.)
Find the assembly for your machine and the letter shown in the "Item" column. The components for your machine will show this
letter or the word "all" in the "Used In" column. The numbers shown in the "Item" column are those shown in the illustrations.
Used In Item Part Number
Description/Nomenclature
Comments
C 38 03 01332 SUPPORT=AIROP AUTOSPOT
C 39 15K020 SKCPSCR 10-24 UNC 3AX3/4 ALLOY
C 40 15U131L FLATWASH #10L (US STD) BRASS
C 41 15N019 RDMACSCR 4-40UNC2AX5/8 ZINC GR
C 42 15U040 LOCKWASHER MEDIUM #4 ZINCPL
C 43 03 01335
INSULATOR=AIROP AUTOSPOT+$8S
C 44 09R014A MINI-SW SPDT STAKON #V-15G-1C26-K
C 45 09R015 ACTUATOR MICRO SWITCH #JV-5
C 45 03 01356 SHAFT-PIVOT=AIROP AUTOSPOT
C 47 15G195 HXNUT 5/16-24UNF2B SAE ZINC GR
C 48 15U210 LOKWASHER MEDIUM 5/16 ZINCPL
C 49 54E005 FLGMTBRG 3/8X1/2X1/2 B#FB68-4
C 50 54E007 PLNBRG 3/8X1/2X3/4 B#6-8-6
C 51 03 01355 SPRING=EXT=AIROP AUTOSPOT
C 52 15N154B FILMACSCR 10-24UNC2AX2 ZINC GR
C 53 27B207 SPCRROLL.202ID.688L.027T STLZC
C 54 12P1AHSB SNAPBUSH .437"MH X .312" T=1/8
C
55 03 01330 ARM=SWLEVER=AIROP AUTOSPOT
C 56 15G131 HXLIGHTLOKNUT 10-32 ESNA22NM02
C
57
15G124C HXMACHSCRNUT 10-32UNF BRASS
C 58 15Q070C SOKSETSCR CUP 10-32X1.25 18-8S
C 59 03 01334 BKT=SW=AIROP AUTOSPOT
C 60 27B206 SPCRROLL.202ID.625L.027T STLZC
D 61 15N152 RDMACSCR 10-24UNC2AX1.25 ZINC
D 62 03 01340 CAM=AIROP AUTOSPOT
D 63 03 01339 SPACER=CAM=AIROP AUTOSPOT
Air Operated Autospot and Sensing Unit
4 Sheets
72044SR2
Control & Sensing
