Pellerin Milnor Corporation 65
page 61 ), the settings of other switch positions are only apparent from this display or by looking
at the processor board.
Display or Action Explanation
Enters the Manual menu from the Run mode.
MANUAL MENU
This is the first item of the Manual menu.
1 SOFTWARE DATE CODE
,
Scrolls down to the Test DIP Switch item.
MANUAL MENU
This is the Test DIP Switch item of the Manual menu.
4 TEST DIP SWITCH
Accesses the Test DIP Switch function and displays the DIP
switch setting.
This is an example of the DIP switch display. Referencing this
number in Table 21: Interpretation of Test DIP Switch Display,
page 65 shows that the sample machine is configured for Correc-
tional Laundries, and that switch position 5 is OFF and 6 is ON.
208
Terminates the Manual menu and returns controller to Run
mode.
NOTICE: If the value that appears on the display is not shown in Table 21: Interpreta-
tion of Test DIP Switch Display, page 65 , add 64, 128, and 192 (the individual values of
switch positions 7 and 8, respectively, and the total of 64 plus 128) to the value on the dis-
play, then check Table 21: Interpretation of Test DIP Switch Display, page 65 for the new
value.
• The values in the "Displayed Value" column of Table 21: Interpretation of Test DIP Switch
Display, page 65 appear on the display only when DIP switch positions 7 and 8 are OFF.
Switch positions 7 and 8 do not affect how the washer-extractor operates.
• If the total of the displayed value plus 64 equals a value in the table, then switch position 7 is
ON.
• If the total of the displayed value plus 128 equals a value in the table, then switch position 8
is ON.
• If the total of the displayed value plus 192 equals a value in the table, then switch positions 7
and 8 are ON.
Table 21. Interpretation of Test DIP Switch Display
Displayed Value Switch Settings Industry
1 2 3 4 5 6 7 8
192 1 1 1 1 1 1 0 0
Correctional
193 0 1 1 1 1 1 0 0
Hotel/Motel
194 1 0 1 1 1 1 0 0
Athletic
