MIMAKI APC-130 User Manual

3-17
3
Convenient use
6
Setting function
Setting the INTERFACE
Set the communication conditions for RS-232C interface connection (connection condition, command
coordinate resolution, data judgment time and data end command).
1
Press the key in LOCAL mode.
2
Press to select [SET UP].
3
Press the key.
4
Press to select [INTERFACE].
5
Press the key.
• “BAUD RATE” setting is displayed.
6
Press to select a set value.
• Setting value : 1200, 2400, 4800, 9600, 19200, 38400 (bps)
7
Press the key.
• The next setting item is displayed.
Set Item Set Value
Connection
condition
BAUD RATE
1200, 2400, 4800, 9600, 19200, 38400 (bps)
DATA BITS
7, 8 (bit)
PARITY
NON, EVEN, ODD
STOP BITS
1, 2 (bit)
HANDSHAKE
AUTO HARD
MGL-IIc HARD, ENQACK, X-PRM, SOFT
MGL-Ic1 HARD, XONOFF
Command
coordinate
resolution
STEP SIZE
AUTO(MGL-IIc) 0.025 (mm)
AUTO(MGL-Ic1) 0.05 (mm)
MGL-IIc 0.025, 0.01 (mm)
MGL-Ic1 0.025, 0.05, 0.1 (mm)
Data judgment
time
CLOSE TIME
3 ～ 60 (sec.)
Data end
command
EOF (End Of File) COMMAND
SP0
ON/OFF
!PG
NR
ZT0
PG
SQUARE CUT <ENT>
SET UP <ENT>
COMMAND < e n t >
INTERFACE <ent>
BAUD RATE : 9600
BAUD RATE : 19200
DATA B I TS : 8 B I TS
