MIMAKI APC-130 - Carriage; Pinch Rollers and Grit Rollers

1-6
Carriage
Pinch rollers and grit rollers
Align the pinch roller to the width of the sheet to be set, and move it to an appropriate position of the grit roller.
Move the pinch roller guessing the “PINCH ROLLER SETTINGS” marks as the measure.
Tool holder
Fix a pen-type cutter for cutting.
(P.2-3)
Pen holder
Fix a rollerball for plotting. ( P.2-5)
Pinch roller
Grit roller
“PINCH ROLLER SETTING”
mark
