MIMAKI APC-130 - The Rear

1-4
The Rear
AC inlet
Connector for the plotter power cable.
(P.1-11)
RS-232C interface connector.
Connect the PC and this machine with the RS-232C interface cable. ( P.1-10)
USB interface connector.
Connect the PC and this machine with the USB interface cable. ( P.1-10)
Clamp pressure lever
Switches the strength of the pressure to
hold the sheet. ( P.1-7)
