3-39
3
Convenient use
6
Setting function
Setting the PEN No. ASSIGN
Allocate the cutter (pen) number (SP command) sent from the host computer when performing cutting (plotting)
to the cutter (pen) number of this device.
1
Press the key in LOCAL mode.
2
Press to select [SET UP].
3
Press the key.
4
Press to select [PEN No. ASIGN].
5
Press the key.
6
Assign the SP1 command to the cutter (pen) number
of this device.
(1) Press to select the cutter (pen) number.
(2) Press the key to register it.
• About screen display
7
Press to move to assign of SP2 and more.
• When you press , the command setting screen of SP2 and
more is displayed.
• Assign to SP2 and more in the same manner of the Step 6.
8
When all settings are complete, press the key.
• Press the key several times to end the setting.
• The pen No. assign setting is valid for MGL-llc command.
• The set values are recorded even when the power has been turned OFF.
SQUARE CUT <ENT>
SET UP <ENT>
COMMAND < e n t >
PEN No . AS I GNe n t >
SP1 : n=12345678
SP1 : n= 1 2345678
SP1 : n= 1 2345678
Cutter (pen) number specified
in the host computer side
Cutter (pen) number of this device
1
CUT1 (Cutter 1)
5
CUT4 (Cutter 4)
2
PEN (Ball point pen)
6
CUT5 (Cutter 5)
3
CUT2 (Cutter 2)
7
CUT6 (Cutter 6)
4
CUT3 (Cutter 3)
8
CUT7 (Cutter 7)
SP2 : n=1 2 345678
