Specification
Item Specification
Settable
sheet
Type of sheet Roll paper (for apparel 64 to 180g/m
2
)
Sheet width 890 to 1400mm
Roll inside
diameter
200mm or less
Weight 20kg or less
Available area for cutting 1240mm x 3000mm
Maximum speed 141cm/s (at plotting, pen moving upward 45 degree direction)
settable speed
(cutting/ plotting)
*1
Plot : Max.60cm/s
Cut : Max.60cm/s
1 ～ 10cm/s (1cm/s step) 10 ～ 60cm/s (5cm/s step)
Mechanical resolution 5μm
Program step
25μm、10μm (MGL-IIc)
100μm、50μm、25μm (MGL-Ic1)
Repetition accuracy ± 0.2mm/3000mm (Excluding extension and shrink of sheet)
Accuracy range
(repetition accuracy)
*2
1240mm x 3000mm (Depending on the specified sheet and the cutting condition)
Maximum pressure 500g
Set pressure
Cutter
10 to 20g (2g step)
20 to 100g (5g step)
100 to 500g (10g step)
Pen
10 to 20g (2g step)
20 to 100g (5g step)
100 to 500g (10g step)100 STEP
Usable tools Cutter, Ballpoint pen (oil-based)
*3
Command
MGL-IIc、MGL-Ic1
Interface
RS-232C、USB
Reception buffer 30M-byte standard (when sorting is valid, 20M-byte)
Operating
environment
Temperature 5 to 35°C
Humidity 35 to 75% Rh (with no dew condensation)
Accuracy-
ensuring
environment
Temperature 16 to 32°C
Humidity 45 to 65% Rh (with no dew condensation)
Dust Equivalent to normal office level
Power capacity AC 100V to 240V 145VA or less
Outside
dimensions
Width 1825mm
Depth 700 to 1110mm
Height 1217mm
Weight 75kg
Noise
During
standby
55dB
When
operating
70dB
*1. Limited depending on the sheet type.
*2. Depending on the condition specified by our company.
• When you use the sheet confirmed by our company only.
• When you perform [Feed count] and [Waiting time] explained in P.2-10 "Reference for cutting condition".
*3. Use the specified extra lead and the dedicated holder.
