3-35
3
Convenient use
6
Setting function
Setting the OVER CUT
Specify whether the over cutting function is enable or unable and
the length of the over cutting.
If the length of the over cutting is set, cutting is performed with extra
cutting space at the front by the specified amount of length at the
start of cutting and tool up is performed at the end going too far.
1
Press the key in LOCAL mode.
2
Press to select [SET UP].
3
Press the key.
4
Press to select [OVER CUT].
5
Press the key.
6
Press to select a set value.
• Setting Value : OFF, 0.1 to 1.0 mm (0.1mm step)
7
Press the key.
8
Press the key several times to end the setting.
• With setting the over cutting
properly, you can reduce the part
remaining uncut at the start/end of
the cutting, especially for the
media easy to bend. However, too
much amount of over cutting
causes to scratches on the media.
• The set values are recorded even
when the power has been turned OFF.
