1-12
Menu mode
This plotter is provided with the following four modes:
NOT-READY mode
The plotter is in this mode until the sheet is detected. The keys other than the key are effective.
LOCAL mode
The plotter enters this mode after the sheet detection.
All the keys are effective.
The plotter can receive data from the computer. However, it will not perform cutting (plotting).
This mode permits the following operations:
(1) Pressing the appropriate JOG keys to move the sheet or carriage little by little or set the origin.
(2) Pressing the key to set functions.
(3) Pressing the key to feed the sheet by the length to be used.
(4) Pressing the key to select a tool or set the tool conditions.
(5) Erase the drawing data that this machine has received with the key.
(6) Pressing the key to make the plotter enter the REMOTE mode.
REMOTE mode
The plotter performs cutting (plotting) according to the received data.
Cutting can be interrupted by pressing the key.
FUNCTION mode
To set the FUNCTION mode, press the key when the plotter is in the LOCAL mode.
Set various cutting (plotting) conditions in this mode.
