Electrical and Pneumatic Connections Theory of Operation
1 - 8 046-006272-00 A7™ Service Manual
S/N From To P/N
25 Total Flow Meter Vaporizer Manifold M6G-020045---
26 Back Pressure Regulator Total Flow Meter M6G-020045---
28 AIR Needle Valve Gas Mixer 082-000518-00
29 O2 Needle Valve Gas Mixer 082-000523-00
34 N2O Cylinder Yoke Y4 082-000662-00
35 Y4 N2O Regulator 082-000662-00
36 Air Cylinder Yoke Y1 or Y4 082-000517-00
37 Y4 Air Regulator 082-000517-00
38 Y4 Y1 082-000521-00
39 O2 Pipeline Pressure Gauge O2 Pipeline Assembly 082-000523-00
40 N2O Pipeline Pressure Gauge N2O Pipeline Assembly 082-000516-00
41 Air Pipeline Pressure Gauge AIR Pipeline Assembly 082-000518-00
42 O2 Regulator Y5 082-000522-00
43 Y5 System Switch 082-000522-00
44 Y5 O2 Flush Button 082-000522-00
45 System Switch Y5 082-000522-00
47 Y4 O2 Regulator 082-000521-00
50 Air Regulator Y5 082-000520-00
51 Y6 Air Needle Valve 082-000518-00
52 O2 Flush Button ACGO Assembly(Electric) 082-000522-00
53 Vaporizer Manifold ACGO Assembly(Electric) M6G-020045---
54 Y4 Air Pipeline Assembly 082-000517-00
55 Exhalation Valve Assembly Gas Reservoir 082-000522-00
57 Y5 Auxiliary O2 Assembly 082-000522-00
58 Electronic Flowmeter Back Pressure Regulator M6G-020045---
59 Y4 O2 Pipeline Assembly 082-000521-00
60 O2 Cylinder Yoke Y1 082-000521-00
61 Y1 Y1 082-000521-00
62 Y4 N2O Pipeline Assembly 082-000662-00
63 Y1 Exhalation Valve Assembly 082-000521-00
64 Auxiliary Air Assembly Y2 082-000520-00
65 Auxiliary O2 Assembly Y2 082-000522-00
66 Y2 Auxiliary Gas Outlet M6G-020026---
67 Y5 Auxiliary Air Assembly 082-000520-00
69 Y1 Auxiliary Gas Outlet 082-000521-00
79 Y4 O2 Pipeline Assembly 082-000521-00
110 Y5 Y6 082-000522-00
111 Y5 Y2 082-000522-00
112 Y2 Drive Valve(UP) 082-000522-00
113 Y2 Drive Valve(DOWN) 082-000522-00
114 Drive Valve(DOWN) ACGO Assembly(Electric) 082-000522-00
115 Drive Valve(UP) ACGO Assembly(Electric) 082-000522-00
To Next Page
