A7™ Ser
vice Manual
046-006272-00
6 - 61
Repair and Disassembly
Disassemble the Assemblies
6.2.12
Remov
e
the A
GSS Assembly
1.
Unplug the
transfer t
ube
s from A
GSS assembly
.
2.
Loose
n the AGSS rail locking knob on the AGSS assembly
. Lif
t the AG
SS assembly along the side
to remo
ve the assembly
.
FIGURE 6-135
418
420
