A7™ Service Manual 046-006272-00 7 - 11
Replacement Parts Introduction
7.1.2.5 Patient Circuit Main Body
FIG.NO. DESCRIPTION PART NUMBER
1 Bellows Dome, A series 801-0631-00054-00
2 Bellows Assembly, A series 0601-30-78968
3 Airway pressure gauge, A series 115-025563-00
4 Breathing circuit unit FRU (A7) 115-027250-00
5 Expiratory Flow Sensor Assembly, A series 801-0631-00056-00
6 Inspiratory / Expiratory Connector, A series 801-0631-00057-00
7 Inspiratory / Expiratory Connector Rotary Cap, A series 801-0631-00059-00
8 Water Collection Cup, A series 801-0631-00058-00
9 Inspiratory Flow Sensor Assembly, A series 801-0631-00060-00
10 Quick release APL valve assembly 115-012263-00
11 Auto/Manual ventilation switch 801-0631-00065-00
12 One-Way Valve 801-0631-00104-00
13
Bag Arm - Fixed Height, A series 115-017033-00
Bag Arm -Flexible arm assembly 115-028041-00
14 Bellows check valve membrane weight 0601-20-69772
15 Test port 043-001285-00
