Mindray A7 Service Manual

A7™ Service Manual 046-006272-00 7 - 27
Replacement Parts Introduction
7.1.2.21 Cables
NO. DESCRIPTION PART NUMBER
1 Cable, Norgren Avm Manifold Assy 009-000066-00
2 Cable, Three Way Valve(ACGO) 009-002592-00
3 Cable, Patient Monitor 009-002927-00
4 Cable, Touchpad 009-000972-00
5 Cable, Display 009-000973-00
6
0631 inverter control high-voltage lines (old)
0632 screen backlight output cable (new)
009-000974-00 (old)
009-006731-00 (new)
7 Cable, Alarm 009-000976-00
8 Cable, Indicator 009-000977-00
9 Cable, Touch Screen 009-000978-00
10 Cable, Ventilator 009-000979-00
11 Cable, Lighting Switch 009-000981-01
12 Cable, Auxiliary Outlet 009-000984-00
13 Cable, Power, AC Internal 009-000985-01
14 Cable, Sodalime Canister Switch Cable 009-000987-00
15
0631 inverter cable B (old)
0635 screen LED backlight input cable (new)
009-000988-00 (old)
009-006382-00 (new)
16 Cable, System Switch 009-001776-00
17 Cable, Top Lighting A 009-000982-00
18 Cable, Display Lighting 009-000986-00
19 Cable, Flow Sensor 009-002481-01
20 Cable, Breathing System 009-002928-00
21 Cable, Flowmeter Switch Signal 009-002929-00
22 Cable, BFCS Position Switch 009-002930-00
23 Cable, Total Flowmeter Backlight 009-002931-00
24 Cable, Encoder Board 009-002932-00
25 Cable, Backup Needle Valve Switch(without N2O) 009-005146-00
26 Cable, Flowmeter 3 way Valve B 009-002937-00
27 Cable, ACGO Valve Status 009-002940-00
28 Cable, Internal AG Module 009-003131-00
29 Line Cord 009-000094-00
30 Cable, O2 Pressure Switch 0621-20-69588
31 Cable, Circuit Switch 0621-20-78593
32 2-pin O2 Sensor Pedestal 801-0631-00067-00
33 Filter Power 250AC 15A Panel Mount 801-0631-00029-00

Mindray A7 Specifications

General

Type	Anesthesia Workstation
Brand	Mindray
Model	A7
Display	15-inch color touchscreen
Oxygen Flush	Yes
Gas Inlets	O2, N2O, Air
Ventilation Modes	SIMV, PSV
Breathing System	Integrated
Gas Monitoring	O2, CO2, N2O
Monitoring Parameters	FiO2
CO2 Monitoring	Mainstream or Sidestream
Power Supply	100-240 V, 50/60 Hz
