Ventilator Control and Drive Theory of Operation
1 - 68 046-006272-00 A7™ Service Manual
B10 VGA_HSYNC
VGA Line Frequency Signal
B11 VGA_VSYNC VGA Field Frequency Signal
B12 GND Ground
B13 TXD_PWR_BRD Power Board Serial Port Transmit Signal
B14 RXD_PWR_BRD Power Board Serial Port Receive Signal
B15 GND Ground
B16 TXD_FLOW_BRD Fresh Flow Sensor Board Serial Port Transmit Signal
B17 RXD_FLOW_BRD Fresh Flow Sensor Board Serial Port Receive Signal
B18 GND Ground
B19 TXD_TOUCH_PANEL Touch Screen Controller Serial Port Transmit Signal
B20 RXD_TOUCH_PANEL Touch Screen Controller Serial Port Receive Signal
B21 OUT2 Backup Output
B22 ACGO_State2 ACGO State Signal 2
B23 GND Ground
B24 NC No Connection
B25 DISPLAY_USB- Display Interface Board USB Data Signal-
B26 DISPLAY_USB+ Display Interface Board USB Data Signal+
B27 GND Ground
B28 NC No Connection
B29 NC No Connection
B30 NC No Connection
B31 NC No Connection
B32 NC No Connection
C1 GND Ground
C2 LVDS-TO0+ LVDS Data Signal
C3 LVDS-TO0- LVDS Data Signal
C4 GND Ground
C5 LVDS-TO1+ LVDS Data Signal
C6 LVDS-TO1- LVDS Data Signal
C7 GND Ground
C8 LVDS-TO2+ LVDS Data Signal
C9 LVDS-TO2- LVDS Data Signal
C10 GND Ground
C11 LVDS-TO3+ LVDS Data Signal
C12 LVDS-TO3- LVDS Data Signal
C13 GND Ground
C14 LVDS-TOC+ LVDS Clock Signal
C15 LVDS-TOC- LVDS Clock Signal
C16 GND Ground
C17 TXD_MON_BRD Ventilator Control Board Serial Port Transmit Signal
C18 RXD_MON_BRD Ventilator Control Board Serial Port Receive Signal
C19 GND Ground
PIN NAME FUNCTION (Continued)
