Mindray BC-2800 Operator's Manual

Understanding the System Principles
3-3
3.3 Dilution
Usually in blood samples, the cells are too close to each other to be identified or counted. For
this reason, the diluent is used to separate the cells so that they are drawn through the
aperture one at a time as well as to create a conductive environment for cell counting.
Moreover, red blood cells usually outnumber white blood cells by 1,000 times. For this reason,
lyse needs to be added to the sample to eliminate the red cells before the WBC counting.

Mindray BC-2800 Specifications

General

Reagents	Diluent, Lyse, Cleaner
Power Supply	AC 100-240 V, 50/60 Hz
Power Consumption	≤150 VA
Printer	Built-in thermal printer
Type	Hematology Analyzer
Parameters	WBC, RBC, HGB, HCT, PLT
Sample Volume	20 μL
Display	Large LCD display
Data Storage	10, 000 sample results
Interface	RS232, USB
Operating Environment	Temperature: 15-30°C, Humidity: 30-85%
Storage Environment	Temperature: -10-55°C, Humidity: ≤93%
